Electrical Steel Wound Core
Electrical Silicon steel is a traditional magnetic material mainly for 50Hz to 1000Hz electronic and electrical applications.
There are several kinds of wound cores in Wuxi Weibang to meet the diversified needs for transformers,inductors,chokes,reactors and sensors,such as current sensor cores, silicon steel transformer core, instrument transformer cores, torodal cores, c-cores, unicore etc. we have mature quality management system to monitor all processes in the production from raw material purchase, splitting,winding,annealing,cutting,coating,inspection,packaging and shipping. It help us ensure product quality and continuous improvement.
Specification：
Brand：WBCORE
Material：CRGO Electrical Steel
Tape Thickness: 0.05~0.5MM
Inner Diameter: 8~700MM
Outer Diameter: ≤1000MM
Edge Chamfered: Available
Plastic Case: Available
Epoxy Coating: Available UL certifacated
Processing:Auto Winding,Annealing
Capacity: 16 Automatic Winding Machines
Custom Design: Available
Standard Size(Ready To Ship):
Inner Diameter/MM | Inner Diameter/MM |
152.5 | 68.3 |
114.2 | 65 |
106 | 60.2 |
105 | 60 |
103 | 55.3 |
100 | 55.2 |
98 | 53.2 |
97.7 | 52.2 |
96 | 52 |
92.2 | 50.3 |
87.6 | 48.3 |
87.5 | 45.2 |
87.5 | 45 |
80.2 | 43.2 |
78.2 | 40 |
77 | 32 |
75.2 | 30 |
74 | 27.2 |
72.2 | 22.8 |
72.2 | 22.7 |
70 | 16.7 |
69.2 |
Application：
Instrument Transformer
Current Transformer
Voltage Transformer
Audio Transformer
Amplifier
